Product Description
The Tamiya M-05 M-Chassis platform receives a significant makeover with the introduction of the NEW M-05 Version II Pro! The M-05 chassis, which was released in 2009, has been a favorite platform for M-chassis club racers for years. The new tweaks and enhancements take advantage of new battery technologies as well as tried and true suspension tweaks used in many of Tamiya’s touring car platforms. Furthermore, it features a number of upgrades, to improve balance and lower the chassis’ center of gravity, using a variety of option parts to make it a highly drivable radio control car.
Option Parts Included
- Aluminum Steering Post
- Aluminum Horn for Hi-Torque Servo Saver
- Full Ball Bearings
- DF-03 Heat Sink Bar Set
- Aluminum Turnbuckle Steering Rod
- CVA Oil-Filled Shocks
- Semi-Gloss Black Plated Wheels
- Aluminum Servo Mount (Blue)
Product Specifications
| Type | Detail |
|---|---|
| Scale | 1/10 |
| Construction type | Assembly kit |
| Terrain use | On-Road |
| Drive-train | 2WD FWD |
| Drive type | Gearbox |
| Drive line | Dog bone |
| Differential type | Gear |
| Suspension | Fully independent double wishbone |
| Steering mechanism | Bell-crank |
| Shock damper | Oil-filled damper |
| Shock damper material | Plastic |
| Tire type | Not included |
| Tire tread | N/A |
| Body material | Not included |
| Chassis material | Plastic |
| Electronic Speed Control (ESC) | Not included |
| ESC model | N/A |
| LED Light buckets | No |
| LED lights | No |
| Motor | N/A |
| Bearings | Shielded ball bearing |
| Adjustable camber | Fixed |
| Adjustable toe angles | Front only |
| Adjustable ground clearance | Yes |
| Adjustable gear ratio | Yes |
| Adjustable wheelbase | Yes |
| Adjustable track width | Fixed |
| Adjustable shock angle | Fixed |
| Special feature 1 | New Feature: The chassis is compatible with square-shaped battery packs. |
| Special feature 2 | New aluminum motor mount designed specifically for the M-05 V.2 chassis. |
| Special feature 3 | Chassis, D parts (arm stays and damper stays, etc.) and wheels have a Semi-Gloss Black metal-plated finish. |
| Special feature 4 | The motor is fitted to a newly-designed mount and has been moved 4.5mm closer to the center of the chassis when compared to the original M-05. |
| Special feature 5 | Improved weight distribution and sharper steering response. |
| Special feature 6 | New suspension arms: one-piece suspension arms are made from reinforced plastic. |
| Special feature 7 | New suspension arms have rebound adjustment with the use of a simple set screw. |
| Special feature 8 | Low Profile Servo Compatibility. |
| Special feature 9 | The servo attachment position has been shifted 8mm downwards to secure a lower center of gravity. |
| Requires A | 2-channel radio gear & electronic speed control |
| Requires B | 7.2 battery & charger |
| Requires C | Body set |
| Requires D | Tires |
