Product Description
In pursuit of Tamiya’s 6th IFMAR World Championship title in the Touring Car class, the Tamiya Racing Factory designers have been hard at work. Their latest creation is the TRF419. The TRF419 is the successor to the TRF418, but it has been heavily tweaked and optimized to give Tamiya’s top drivers the best chance in securing the 2014 World Title.
TRF418 VS. TRF419 differences:
- Inherits the new TRF418 suspension parts.
- Aside from the suspension parts, the rest of the chassis features a whole range of updates and new parts.
- Carbon fiber upper and lower decks have been redesigned for optimum chassis balance and to maximize the potential of the new drivetrain parts.
- Oil-filled Dampers follow a new design, and combined with new carbon fiber stays will provide excellent traction on a range of track surface conditions.
- The new aluminum motor mount ensures that the chassis’ supreme flexibility is fed back more efficiently. The motor position is altered to optimize weight distribution.
- Features newly-designed bulkheads, motor mount, dampers and gear differential unit.
Newly Designed parts include:
- Carbon Lower Deck
- Carbon Upper Deck
- Carbon Front/Rear Damper Stays
- Aluminum Motor Mount
- Aluminum F/R Lower Bulkheads
- Aluminum F/R Upper Bulkheads
- Steel Center Pulley Shaft
- Aluminum Servo Mount
- Front/Rear Drive Belts
- Gear Differential Unit Front Direct Coupling
- Dampers
- Aluminum Suspension Mounts
Product Specifications
| Type | Detail |
|---|---|
| Scale | 1/10 |
| Construction type | Assembly kit |
| Terrain use | On-Road |
| Drive-train | 4WD |
| Drive type | Belt |
| Drive line | Universal |
| Differential type | Sealed oil filled gear and Spool |
| Suspension | Fully independent double wishbone |
| Steering mechanism | Bell-crank |
| Shock damper | Oil-filled damper |
| Shock damper material | Aluminum |
| Tire type | Not included |
| Tire tread | N/A |
| Body material | Not included |
| Chassis material | Carbon fiber plate |
| Electronic Speed Control (ESC) | Not included |
| ESC model | N/A |
| LED Light buckets | No |
| LED lights | No |
| Motor | N/A |
| Bearings | Sealed ball bearing |
| Adjustable camber | Yes |
| Adjustable toe angles | Front and rear |
| Adjustable ground clearance | Yes |
| Adjustable gear ratio | Yes |
| Adjustable wheelbase | Yes |
| Adjustable track width | Yes |
| Adjustable shock angle | Yes |
| Special feature 1 | TRF418 suspension parts. |
| Special feature 2 | New design aluminum dampers |
| Special feature 3 | New motor mount |
| Special feature 4 | New oil filled differential unit |
| Special feature 5 | Aluminum bulkheads |
| Special feature 6 | Carbon fiber lower and upper chassis plates |
| Special feature 7 | New front and rear drive belts |
| Special feature 8 | Steel center pulley shaft |
| Special feature 9 | Front and rear carbon fiber damper stays |
| Special feature 10 | Aluminum Servo Mount |
| Requires A | 7.2 battery & charger |
| Requires B | 2-channel radio gear |
| Requires C | Wheels, tires, body set, motor, esc |
